The Wöhr Combilift puzzle lift parking system was one of the first puzzle systems installed in the United States during the early 2000s. These puzzle car parking systems are considered the entry level into automated parking systems. The Combilift “puzzle parking system” is a semi-automated mechanical puzzle parking lift system designed and manufactured in Germany with the American consumer and real estate developer in mind.
Harding Steel first brought these puzzle car parking systems to market in the US on a national scope with installations across the country. Combilift is our most in-demand automated parking system solution for multi-family independent parking, as these pit puzzle parking systems can be individually configured for each building, project, and parking requirement. Because these puzzle car parking systems are so easy to use, Combilift virtually eliminates the need for attended or valet parking operators.
Puzzle parking systems benefit property owners as well as the end users who might visit the locations where these pit puzzle parking systems are used. These puzzle car parking systems take up much less space than a typical parking garage or parking lot does because they stack vehicles vertically. Plus, instead of taking the time to find a parking space and then searching for your car when you’re finished, you can simply park and let this puzzle lift parking system retrieve your car for you.
ADVANTAGES
No exposed lifting or lower chains that cause injury or damage
All hydraulic lifting, for virtually silent operation and high-speed reliability
Industry-exclusive sliding gates design systems with options for aluminum finishes, wood paneling, or glass
All controls feature Standard RFID Chips
Optional Smartphone Applications for both iOS and Android devices
Optional smooth plate platforms (low profile galvanized and aluminum options)
Weight capacity up to 4,400 lbs are available
All controls are UL compliant and internally mounted inside the system saving wall space.
STANDARD SPECS
220V 3ph 20 amp electrical service
4,400 lbs capacity
All galvanized steel construction
Modular design for ease of fabrication and installation
Requires structural support at the rear of the system from building systems
Widths up to 106” available on each platform
1 year parts and labor warranty, 2 years parts, 5 years structure
WARRANTY
Your parts and labor are covered for one year.
